Capacity

30000 Kg

Height

11,72 m

Engine Power

235 kW

30.12

Capacity

30000 Kg

Height

11,72 m

Engine Power

235 kW

The HTH 16.10 telehandler is ideal for safely handling heavy and bulky loads. Capable of lifting up to 16 tons, it is compatible with numerous accessories that make it extremely versatile. Equipped with an RFID system that allows automatic recognition of the various accessories used, this telehandler is able to respond to countless applications in the heavy industry sector.

The 4-wheel drive, 3 steering modes, and high ground clearance give it great maneuverability on all terrains.

The standard configuration of the machine includes:

Comfort seat
Adjustable steering column
Analog joypad
Heating
Air conditioning
FM/AM radio with USB and Bluetooth connectivity
USB Type-A inputs (5V)

7-inch touch screen
MCTS – Magni Combi Touch System on-board software
Automatic RFID attachment recognition system
LMI – Load control system
Integrated on-board and remote diagnostics

Technical Data

Metrico
CaratteristicaMetricoImperiale
Stabilizers--
Lifting Capacity30000 Kg66100 lbs
Maximum Height Capacity15000 Kg33100 lbs
Lifting Height11.72 m37' 5''
Max reach6.86 m22' 6''
EngineVolvo TAD 883 VE - Stage VVolvo TAD 883 VE - Stage V
Rated Power235kW 320hp 2200rpm235kW 320hp 2200rpm
Travel--
Hydraulic Flow Rate--
Number of Gears2/22/2
Hydraulic system350 bar-
Length7.95 m26' 1.05''
Width3 m9' 10''
Ground Clearance550 mm1' 9.98''
Unladen Weight37600 Kg82.900 lbs
Speed25 km/h15 mph
Rotation--
Standard Air ConditioningSiSi
Automatic Attachment RecognitionSiSi
Reversible FanSiSi

Compatible accessories

Forklifts

Forklifts

Special

Special

Platforms

Platforms

Hooks

Hooks

Loaders

Loaders

Grippers

Grippers

Booms

Booms

Winches

Winches

Optional

Setups and Certifications

Setups and Certifications

Comfort

Comfort

Performance

Performance

Safety

Safety

Specials

Specials
